The 691361100002 is a 2-position vertical pluggable Terminal Block with PA66 (polyamide66) insulator, tin-plated phosphor bronze (PhBz) wire guard, brass (CuZn) metal housing, green colour. Zinc-plated steel - slot type terminal screw, M2 screw, 3.50mm pitch spacing, 1.5mm2 conductor cross-section area, 6 to 7mm strip length and 26 to 16mm stranded wire.
- UL94V-0 Flammability rating
- 0.2Nm Torque
- 20mR Maximum contact resistance
- 1.6kV Withstanding voltage
