The 250-204 is a 4-position PCB Terminal Block with polyamide 6.6 (PA 6.6) insulator, 3.5mm pin spacing, copper alloy clamping spring and contacts with tin-plated and grey colour. 1.5mm2 cross-section, push-in wire connection method, 24 to 16AWG wire size and through hole 45° block orientation.
UL94V-0 Flammability rating
4kV Measured shock voltage
Compact terminal strips with pushbuttons
Simple push-in terminations of solid and ferruled conductors
Termination/removal of fine-stranded conductors via push-buttons
