The DRV5053OAQLPG is an Analogue Bipolar Hall Effect Sensor, chopper-stabilized Hall IC that offers a magnetic sensing solution with superior sensitivity stability over-temperature and integrated protection features. The 0 to 2V analogue output responds linearly to the applied magnetic flux density and distinguishes the polarity of magnetic field direction. A wide operating voltage range from 2.5 to 38V with reverse polarity protection up to -22V. Internal protection functions are provided for reverse supply conditions, load dump and output short circuit or over-current.
Linear output hall sensor
Superior temperature stability, sensitivity ±10% over-temperature
-11 (OA), -23 (PA), -45 (RA), -90 (VA), +23 (CA) and +45mV/mT (EA) High sensitivity options
Supports a wide voltage range (2.5 to 38V)
No external regulator required
Wide operating temperature range (TA = -40 to 125°C (Q))
2.3mA Sink, 300μA source amplified output stage
0.2 to 1.8V Output voltage (B = 0mT, OUT = 1V)
35μs Fast power-on
Supports reverse supply Pr load dump, output short-circuit and output current limitation protection
