DRV5033AJQLPG -

制造商：

TEXAS INSTRUMENTS TEXAS INSTRUMENTS

制造商产品编号：

DRV5033AJQLPG

仓库库存编号：

2455495

技术数据表：

(EN)

The DRV5033AJQLPG is a 2.5 to 38V digital omnipolar-switch chopper-stabilized Hall-effect Sensor that offers a magnetic sensing solution with superior sensitivity stability over-temperature and integrated protection features. The DRV5033 responds the same to both polarities of magnetic field direction. When the applied magnetic flux density exceeds the BOP threshold, the sensor open drain output goes low. The output stays low until the field decreases to less than BRP and then the output goes to high impedance. The output current sink capability is 30mA. A wide operating voltage range from 2.5 to 38V with reverse polarity protection up to -22V makes the device suitable for a wide range of industrial applications. Internal protection functions are provided for reverse supply conditions, load dump and output short-circuit or over-current.

• No external regulator required
• Open drain output 30mA sink
• Fast 35μs power-on time
• Reverse supply protection
• Supports up to 40V load dump
• Output short-circuit protection
• Output current limitation
• Detects north and south magnetic field
• Green product and no Sb/Br
