The ULN2801A is a 50V Eight Darlington Array designed for general purpose applications with a current limit resistor. The array contains eight Darlington transistors with common emitters and integral suppression diodes for inductive loads. Each Darlington features a peak load current rating of 600mA (500mA continuous) and can withstand at least 50V in the off state. Outputs may be paralleled for higher current capability.
Integral suppression diodes
Versions for all popular logic families
Output can be paralleled
Inputs pinned opposite outputs to simplify board layout
