The STM32L051C8T6 is a Microcontroller Unit, incorporates the high-performance ARM? Cortex?-M0+ 32-bit RISC core operating at a 32MHz frequency, a memory protection unit (MPU), high-speed embedded memories plus an extensive range of enhanced I/Os and peripherals. This device provide high power efficiency for a wide range of performance. It is achieved with a large choice of internal and external clock sources, an internal voltage adaptation and several low-power modes.
Ultralow-power platform
1.65 to 3.6V Power supply
0.27μA Standby mode (2 wakeup pins)
139μA/MHz Run mode at 32MHz
From 32kHz up to 32MHz maximum
Ultra-safe, low-power BOR with 5 selectable thresholds
Ultralow power POR/PDR
Programmable voltage detector (PVD)
1 to 25MHz Crystal oscillator
32kHz Oscillator for RTC with calibration
Pre-programmed boot loader
Serial wire debug supported
Rich analogue peripherals (down to 1.8V)
12-bit ADC 1.14Msps Up to 16 channels (down to 1.65V)
