The 1825-4 is a yellow Standard Banana Plug in solderless and stackable style. Designed to fit on the end of any 22AWG to 18AWG wire. Cross hole wire entry fits wires up to 0.12-inch (3mm) diameter. Available with tarnish resistant nickel or gold plating for very low contact resistance. Gold plated beryllium copper banana jack. Nickel plated brass banana plug with nickel plated beryllium copper spring. Polypropylene insulation, zinc plated steel set screw and 8-32 threaded single slot.
- Fits standard panel and binding post banana jacks 0.161 to 0.166" (4.0 to 4.2mm) diameter
- Cross hole wire entry fits wires up to .12" (3mm) diameter
- Available with tarnish resistant nickel or gold plating for very low contact resistance
- Set screw simplifies assembly of test leads and jumpers by using a flat blade screwdriver for easy wire attachment
- Fits standard panel and binding post banana jacks .161" to .166" (4,0mm to 4,2mm) diameter
- Integral safety collar insulates wire conductor and offers wire strain relief
- Beryllium copper springs for long insertion life
- Vertical stack-up feature offers test versatility
