The 1825-1 is a solderless and stackable Standard Banana Plug with nickel-plated beryllium copper contacts. It comes with brown polypropylene insulation and zinc-plated steel set screw. The plug is designed to fit on the end of any 22 to 18AWG wire range. Set screw simplifies assembly of test leads and jumpers by using a flat blade screwdriver. This 1825 series plug fits standard panel and binding post banana jacks of 0.161 to 0.166-inch diameter.
- Designed to fit on the end of any 22 AWG to 18 AWG wire
- Cross hole wire entry fits wires up to .12" (3mm) diameter
- Available with tarnish resistant nickel or gold plating for very low contact resistance
- Set screw simplifies assembly of test leads and jumpers by using a flat blade screwdriver for easy wire attachment
- Fits standard panel and binding post banana jacks .161" to .166" (4,0mm to 4,2mm) diameter
- Integral safety collar insulates wire conductor and offers wire strain relief
- Beryllium copper springs for long insertion life
- Vertical stack-up feature offers test versatility
