The 1325-4 is a yellow Standard Banana Plug in solderless and stackable style. Designed to fit on the end of any 22AWG to 18AWG wire. Cross hole wire entry fits wires up to 0.12-inch (3mm) diameter. Available with tarnish resistant nickel or gold plating for very low contact resistance. Gold plated beryllium copper banana jack. Nickel plated brass banana plug with nickel plated beryllium copper spring. Polypropylene insulation, zinc plated steel set screw and 8-32 threaded single slot.
Fits standard panel and binding post banana jacks 0.161 to 0.166" (4.0 to 4.2mm) diameter
