The MSTB 2,5/12-STF-5,08 from Phoenix Contact is a 5.08 pitch, COMBICON plug-in PCB connector with 12 position. The plug-in direction parallel to the conductor axis with wire gauge range from 24AWG to 12AWG.
Nominal current is 12A
Rated voltage (III/3) is 250V, (III/2) is 320V, (II/2) is 630V
Green colour polyamide insulating material
Connection capacity is 0.2mm2 to 2.5mm2 (solid), 0.2mm2 to 2.5mm2 (stranded)
Flammability rating according to UL 94 V0
Screwable flange for superior mechanical stability
