The MC 1.5/4-ST1-5.08 is a 4-position 5.08mm MINI COMBICON plug-in connector base strip Terminal Block with PA (polyamide) insulator, green colour, tin contact surface. Suitable for wave soldering processes. 1.5mm2 nominal cross-section, screw wire connection method and M2 screw thread. Individual position coding by removing the coding tab and connecting the coding profile to the header. ST1 version with plug-in area moved to the bottom, lies flush with the bottom edge of the housing.
