The 1726163 is a 3-position 13.5A green wire-to-board Terminal Block with tin-plated contact surface and a polyamide insulator. The MKKDSN 1,5/ 4-5,08 terminal block has screw connection with tension sleeve and 0° conductor/PCB connection direction.
UL94V-0 Flammability rating
M3 Screw thread size
Offset levels for optimum access to the terminal points
Compact housing dimensions and low design height
Double-level type with high packing and connection density
