The MAX9028EBT+T is a 1.8V, nanopower comparator in 6 pin UCSP package. The device consume 0.6μA of supply current and operates down to +1.8V. The common mode input voltage range extends 200mV beyond the rails. This unique design of the output stage limits supply current surges while switching and virtually eliminate the supply glitches of many other comparators. It also minimizes overall power consumption under dynamic conditions. It has an open-drain output stage that makes it suitable for mixed-voltage system design. This device is ideal for all 2-cell battery monitoring/management applications.
Supply voltage range is 1.8V to 5.5V
Operating temperature range from -40°C to 85°C
Crowbar current free switching
No phase reversal for overdriven inputs
Input offset voltage is ±0.3mV
Input bias current is 0.15nA
Power supply rejection ratio is 0.1mV/V and common mode rejection ratio is 0.5mV/V
Internal hysteresis ensures clean output switching even with slow moving input signals
