The 2410 03 is a 4-pole Type-A Double USB 2.0 Chassis Socket, 24 series, angular version for printed circuit boards. UL94V-0 flame-rated polybutylene terephthalate (PBT) insulating body, nickel-plated brass housing, gold-plated bronze contact. Suitable for use with 2410 07, 2410 08, 2431, 2480 and 2482 USB plug.
- <=30N Insertion force
- >=10N Withdrawal force
- 1500 Mating cycles
- <=30mR Contact resistance
- <=1A Rated current
- 30VAC Rated voltage
- >=100MR Insulation resistance
