The M50-9110542 is a 300mm 10-way IDC Ribbon Cable Assembly, female-to-female connectors, UL94V-0-rated black PBT housing, 100% tin-plated over nickel termination, gold-plated contact surface and phosphor bronze contact. IDC contact for high speed termination. Polarised to prevent mis-mating and secure cable retention with positive latching to header.
- 1.27mm (0.05") Contact pitch
- Angled connector orientation
- 0.5A Current rating
- 1R Maximum contact resistance
- 5MR Minimum insulation resistance
- 300VDC Minimum working voltage
- -40 to +105°C Operating temperature range
