The ADIS16364BMLZ is an iSensor? Inertial System that includes a 3-axis gyroscope and triaxis accelerometer. The device combines industry-leading iMEMS? technology with signal conditioning that optimizes dynamic performance. The ADIS16364 provides a simple method for integrating accurate, multiaxis inertial sensing into industrial systems, especially when compared with the complexity and investment associated with discrete designs. All necessary motion testing and calibration are part of the production process at the factory, greatly reducing system integration time. Tight orthogonal alignment simplifies inertial frame alignment in navigation systems. An improved SPI interface and register structure provide faster data collection and configuration control. The device uses a compatible pin-out and the same package as the ADIS1635x family.
<0.05° Tight orthogonal alignment
330Hz Wide sensor bandwidth
Autonomous operation and data collection no external configuration commands required
180ms Start-up time
4ms Sleep mode recovery
Factory-calibrated sensitivity, bias and axial alignment
-20 to +70°C Calibration temperature range
Embedded temperature sensor
Automatic and manual bias correction controls
Bartlett window FIR filter length, number of taps
Digital I/O - Data-ready, alarm indicator, general-purpose
